Honeywell UDC2800 User Manual

Step Operation Press Result
When the motor stops, the display should stop
counting, then go to the next step.
4 Do Auto
Set 100 %
value
Function
key
Back to the configuration prompt Position
Proportion.
Increment
key or
Decrement
key
Until you see Span Value.
The increment relay is turned on to move the
motor to 100% position.
When the motor stops, the display should stop
counting, then, go to Step 7.
5 Do Manual
Set 0 % value
Function
key
Back to the configuration prompt Position
Proportion.
Increment
key or
Decrement
key
Until you see Zero Value.
Function
key
Enter into configuration prompt of Zero Value.
Increment
key or
Decrement
key
Change the value.
6 Do Manual
Set 100 %
value
Function
key
Back to the configuration prompt Position
Proportion.
Increment
key or
Decrement
key
Until you see Span Value, and press the
function key to change the value.
For manual calibration, the motor does not
move from its position prior to the start of
Position Proportional calibration.
Function
key
Enter into configuration prompt of Span Value.
Increment
key or
Decrement
key
Change the value.
249
Chapter 7 - Output Calibration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
