Honeywell UDC2800 User Manual

NOTE: If the required controller is not listed, click the
Refresh icon to refresh the page.
4. Select the controller which Bluetooth ID is matched with UDC
device, the connect dialog appears.
5. Click CONNECT, Bluetooth pairing request dialog appears.
NOTE: The UDC device receives a pairing code. Record the
code.
6. Enter the UDC device paining code, and then click Pair.
285
Chapter 10 - Configuration via Honeywell EasySet

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
