Table III - Input 1 and Input 2
Input 1
(See Note 1
)
TC, RTD, mV, 0-5V, 1-5V, 0-10V 1 _ _ • •
TC, RTD, mV, 0-5V, 1-5V, 0-10V, 0-20mA, 4-
20mA
2 _ _ • •
Input 2 None _ 00 • •
TC, RTD, mV, 0-5V, 1-5V, 0-10V _ 10 • •
TC, RTD, mV, 0-5V, 1-5V, 0-10V, 0-20mA, 4-
20mA
_ 20 • •
Slidewire Input for Position Proportional
(Requires 2 Relay Outputs)
_ 40 a a
Carbon, Oxygen or Dewpoint (Provides 2
Inputs)
_ 60 b b
Note 1: Input 1 can be changed in the field using external resistors.
Table IV - Options
Approvals CE (Standard)
CE, UL and CSA
0 _ _
1 _ _
•
•
•
•
Tags None
Stainless Steel Customer ID Tag - 3 lines w/22
characters/line
_ 0 _
_ T _
•
•
•
•
Future
Options
None _ _ 0 • •
Table V - Documentation
Documents Quick Start Guide - English 0 _ • •
Certificate None
Certificate of Conformance (F3391)
_ 0
_ C
•
•
•
•
Table VI - Extended Warranty
Extended
Warranty
None
Extended Warranty Additional 1 year
Extended Warranty Additional 2 years
0
1
2
•
•
•
•
•
•
41
Chapter 3 - Installation

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
