Honeywell UDC2800 User Manual

Description Part Number
Auxiliary Output/Digital Input/Ethernet Communications PWA 51308448-528
Analog Input/Control Output (1ch Ai), PWA 51308452-526
Analog Input/Control Output (2ch Ai), PWA 51308452-527
MCU/Display PWA 51308456-526
Dual Electromechanical Relay PWA 51308458-526
Current Output PWA 51308460-526
Open Collector Output PWA 51308462-526
Ethernet Adaptor Board Kit 50009071-501
Electro-Mechanical Relay 51508015-505
4-20 mA Input Resistor Assembly (250 ohm) 30731996-506
CHASSIS ASSEMBLY, UDC 50150597-501
Case Assembly (including Mounting Kit with four brackets) 51452759-501
Mounting Kits (12 Brackets) 51452763-501
DIN Adaptor Kit 30755223-003
Panel Bracket Kit 50004821-501
Quick Start Guide English 51-52-25-158
Product Manual English 51-52-25-157
ATTENTION: It is recommended to use Honeywell provided
accessories and kits. Otherwise, using non-Honeywell provided
components would take risks.
43
Chapter 3 - Installation

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
