A19
Graphics Processor
Tools
Required
n
T-10 TORX screwdriver
n
T-15 TORX screwdriver
n
ESD (electrostatic discharge) grounding wrist strap
Removal
1. Disconnect the power cord.
2. Remove the top cover (refer to “Covers” in this chapter) and front panel
(refer to
“Front
Panel Assembly” in this chapter.)
3. Remove the six screws (item 1) from the GSP cover (item 2) and lift off.
4. Swing out the handles (item 3) and pull the GSP board (item 4) out of the
analyzer.
Replacement
1. Check the connector pins on the motherboard before
reinstaktion.
2. Reverse the order of the removal procedure.
1444
Assembly Replacement and Psi-Repair Procedures
