G
good trace display, 8-5
green LED on Al5
power supply shutdown, 12-6
green LEDs on A8, 12-7
GSP
digital control, 12-12
H
hardkeys, 19-2
hardware
bottom view, 13-30
disk drive, 13-36
front view, 13-32
memory deck, 13-38
part numbers, 13-28-49
preregulator, 13-40
test set deck, 13-34
top view, 13-28
HB FITR SW ON OFF, 1919
Hewlett-Packard servicing, 42
high band REF signal, 7-17
high/Iow band transition adjustment,
3-52
High/Low Band Transition Adjustment
Sequence, 3-62
high quality comb tooth at 3 GHz,
7-33
high stabiiity frequency reference
assembly replacement, 1458
part numbers, 13-26
HI OUT signal in FRACN TUNE mode,
7-34
H MB line, 7-31
how to
adjust ADC offset correction
constants, 3-17
adjust analog bus correction
constanti, 3-9
adjust cavity oscillator frequency
correction constants, 3-28
adjust fractional-N frequency range,
3-45
adjust fractional-N spur avoidance
and FM sideband, 3-54
adjust frequency accuracy, 3-48
adjust hig.hAow band transition,
3-52
adjust IF ampiifIer correction
constants, 3-16
adjustment the analyzer, 3-l
adjust option numbers correction
constants, 3-36
adjust RF output power correction
constants, 3-l 1
adjust sampler magnitude correction
constants, 3-18
adjust serial number correction
corl!stants,3-34
adjust source default correction
constants, 3-7
adjust source pretune correction
constants, 3-10
adjust source pretune default
correction constants, 3-8
adjust source spur avoidance
tracking, 3-58
adjust the anaIyzer using sequences,
3-62
backup the EEPROM disk, 3-38
check display intensity, 6-7
clean connectors, l-5
identify the faulty functional group,
4-9
initialize EEPROMs, 3-37
load sequences from disk, 3-62
position the A9 Switch, 3-5
repair the analyzer, 4-l
retrieve correction constant data
from EEPROM backup disk,
3-40
IndlBx-11
