SOURCE POWER TURNED OFF,
RESET UNDER POWER MENU,
lo-59
source pretune correction constants
adjustment, 3-10
source prettme default correction
constants adjustment, 3-8
source spur avoidance tracking
adjustment, 3-58
source troubleshooting chapter, 7-l
specifications
external source mode frequency
range, 2-21
minimum R channel level, 2-31
test port input noise floor level,
2-37
test port output frequency range
and accuracy, 2-18
test port output power accuracy,
2-24
test port output power range and
linearity, 2-27
spectrum analyzer, 1-3
speed
fan, 5-22
spikes display (acceptable versus
excessive), 3-59
splitter (power), l-4
spur avoidance and PM sideband
adjustment, 3-54
spur avoidance tracking adjustment,
3-58
SPUR AVOID ON OFF, lo-22
spurs displayed with a filter, 3-30
spur search with a filter, 3-30
spur search without a filter, 3-31
SPUR TEST ON OFF, lo-21
SRAM RAM, lo-8
SRC ADJUST DACS, lo-19
SRC ADJUST MENU, lo-19
SRC TUNE FREQ, lo-19
SRC tune mode frequency output,
7-8
SRC tune mode phase locked output
compared to open loop, 7-9
SRC tune mode waveform integrity,
7-9
SRC TUNE ON OFF, lo-19
stable HI OUT signal in PRACN TUNE
mode, 7-34
Start Troubleshooting chapter, 4-l
static-control table mat and earth
ground wire, l-4
status terms for test, 19-4
step attenuator, 1-3
STORE EEPR ON OFF, lo-21
stuck key identification, 6-14
support and service options, 1-9
SWEEP MODE CHANGED TO CW
TIME SWEEP, lo-60
Sweep Trig., 19-10
switch position adjustment, 3-5
symbol conventions, 19-48
system performance uncorrected,
11-9
system verihcation
description of, 2-l
post-repair, 3-2, 14-62
system verification (automated), 2-8
system verification cycle, 2-7
system verification tests, 193,19-12
Sys Ver hut., 19-12
SYS VER TESTS, lo-4
T
table of service tools, l-l
temperature check, 5-13
terms for test status, 19-4
test 44, 3-7, 19-13
test 45, 3-8, 19-13
test 46, 3-9, lo-13
test 47, 3-11, 19-13
Index-21
