Table 5-29 Attributes of the RS485 interface
Attribute Specification
Connector type RJ45
Compliance
standard
RS-485
l Table 5-30 describes the attributes of the MON interface.
Table 5-30 Attributes of the MON interface
Attribute Specification
Connector type RJ45
Compliance
standard
RS-232
5.6.6 Technical Specifications
Table 5-31 describes the technical specifications of the CMU.
Table 5-31 Technical specifications of the CMU
Item
Specification
Board dimensions
(depth x width x
height)
412.7 mm x 112.9 mm x 19.8 mm
Maximum power
consumption
1 W
Weight 0.22 kg
5.7 SPU - VAMPA VAS Board
This section describes the VAMPA value-added service (VAS) board, including the appearance,
functions and features, applicable devices, slots, panel, indicators, interfaces, and technical
specifications.
5.7.1 Introduction
5.7.2 Function and Application
5.7.3 Panel
