Table 5-85 Description of buttons and indicators on the S24XA panel
Indicator/Button Color Meaning
RUN/ALM Green If the indicator is on, it indicates that the board
is powered on but the software is not running.
If the indicator blinks once every 2s (0.5 Hz),
it indicates that the system is in normal state.
If the indicator blinks once every 0.25s (4 Hz),
it indicates that the system is being powered
on or being restarted.
Red
If the indicator is in red, it indicates that the
board is faulty.
Orange If the indicator is in orange, it indicates that
the board is installed in the slot and the CBUS
is powered on.
ACT Amber If the indicator blinks, it indicates that data is
being transmitted.
LINk Green-yellow If the indicator is on, it indicates that the link
is connected.
5.16.4 Interfaces
Table 5-86 describes the types and functions of the interfaces on the S24XA.
Table 5-86 Types and functions of the interfaces on the S24XA
Name
Quantity Description
100M/1000M BASE-X
optical interface
24 The S24XA provides 24 Ethernet optical
interfaces (100M/1000M auto sensing) to transmit
and receive Ethernet services at 1000 Mbit/s.
10G BASE-X optical
interface
2 The S24XA provides two 10GE optical interfaces
to transmit and receive Ethernet services at 10
Gbit/s.
5.16.5 Interface Attributes
The S24XA provides only data interfaces. Each interface has an optical module. The S24XA
provides GE optical interfaces and 10GE optical interfaces.
l Table 5-87, Table 5-88 and Table 5-89 describe the attributes of the GE interfaces and the
connected optical modules.
