Buttons and Indicators on the SRU Panel
Table 5-8 describes the buttons and indicators on the SRU panel.
Table 5-8 Description of the buttons and indicators on the SRU panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the SRU
is powered on, but the software is not running.
If the indicator blinks every 2s (0.5 Hz), it
indicates that the system is running normally.
If the indicator blinks every 0.25s (4 Hz), it
indicates that the system is starting.
Red
If the indicator is in red, it indicates that the
SRU is faulty.
Orange If the indicator is in orange, it indicates that
the SRU is installed, and the board is powered
on.
ACT Green This indicator shows whether the SRU is the
master SRU or slave SRU.
If the indicator is on, it indicates that the SRU
is the master SRU.
If the indicator is off, it indicates that the SRU
is the slave SRU.
RST
- Press this button to reset the SRU.
NOTE
Resetting the SRU will cause the loss of service
packets. Confirm the operation before you press the
Reset button.
SYNC Green If the indicator is on, it indicates that the
device supports the time and clock
synchronization and the clock board is
installed on the SRU.
If the indicator is off, it indicates that the
device supports the time and clock
synchronization but the clock board is not
installed on the SRU.
5.2.4 Interfaces
Table 5-9 describes the types and functions of the interfaces on the SRU.
