Huawei Quidway S9300

Table 6-4 Technical specifications of the AC power cables out of the cabinet
Item Description
Power cable Electronic and electrical cable-300 V-227IEC10(BVV)-6 mm^2-
Black jacket (core: blue, brown, yellow/green)-36 A-3 cores with
equal cross sections
Terminal 35 mm^2 power cable terminal
6.3 Grounding Cable
This section describes the structure and technical specifications of the grounding cables.
6.3.1 Introduction
6.3.2 Structure
6.3.3 Technical Specifications of the S9300 Grounding Cables
6.3.1 Introduction
The grounding cables connect the S9300 and cabinet to the ground. The grounding cables in the
front, rear, and side doors of the cabinet have been properly connected before delivery.
6.3.2 Structure
The appearance of grounding cable terminals and the DC power cable terminals is the same.
6.3.3 Technical Specifications of the S9300 Grounding Cables
Table 6-5 shows the technical specifications of the grounding cables of the cabinet.
Table 6-5 Technical specifications of the S9300 grounding cables
Item
Specification
Cable Electronic and electrical cable-450V/750V-H07Z-K-6 mm^2-
Yellow-green-Low-fume, halogenless and flame-retardant cable
Terminal Bare crimping terminal-OT-6 mm^2-M6-Tin plating-Round pre-
insulated terminal-12 to 10 AWG-Yellow
6.4 Console Cable
This section describes the structure and technical specifications of the Console cable.
6.4.1 Introduction
