Huawei Quidway S9300

Table 5-94 describes the types and functions of the interfaces on the T24XA.
Table 5-94 Types and functions of the interfaces on the T24XA
Name Quantity Description
10M/100M/1000M
BASE-X electrical
interface
24 The T24XA provides 24 Ethernet electrical
interfaces (10M/100M/1000M auto sensing) to
transmit and receive Ethernet services at 1000
Mbit/s.
10G BASE-X optical
interface
2 The T24XA provides two 10GE optical interfaces
to transmit and receive Ethernet services at 10
Gbit/s.
5.17.5 Interface Attributes
The T24XA provides only data interfaces. Each interface has an optical module. The T24XA
provides GE electrical interfaces and 10GE optical interfaces.
l Table 5-95 lists the attributes of the 100M/1000M Base-T electrical interface.
Table 5-95 Attributes of the 100M/1000M Base-T Ethernet interface
Attribute
Description
Connector type RJ45
Compliance
standard
IEEE 802.3z
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
l Table 5-96 and Table 5-97 describe the attributes of the 10GE interfaces and the connected
optical modules.
Table 5-96 Attributes of the 10G Base-XFP optical interface
Attribute
Description
Connector type LC/PC
Optical interface
attribute
Depending on the SFP optical module. For details about the attributes
of the optical module, see Table 5-97.
Compliance
standard
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
