Huawei Quidway S9300

Table 5-108 Attributes of the 10G Base-XFP optical interface
Attribute Description
Connector type LC/PC
Optical interface
attribute
Depending on the SFP optical module. For details about the attributes of
the optical module, see Table 5-109.
Compliance
standard
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
Table 5-109 Attributes of the SFP+ optical module (10 Gbit/s)
Attribute Description
Transmission
distance
300 m 10 km 40 km
Center
wavelength
850 nm 1310 nm 1550 nm
Transmitting
power
-7.3 dBm to -1 dBm -8.2 dBm to 0.5 dBm -4.7 dBm to 4.0 dBm
Receiver
sensitivity
-11.1 dBm -12.6 dBm -14.1 dBm
Overload
optical power
-1.0 dBm 0.5 dBm -1.0 dBm
Extinction ratio 3 dB 3.5 dB 3 dB
Fiber type Multi-mode Single-mode
5.19.6 Technical Specifications
Table 5-110 describes the technical specifications of the X12SA.
Table 5-110 Technical specifications of the X12SA
Item
Specification
Board dimensions
(depth x width x
height)
426.8 mm x 394.7 mm x 35.1 mm
