Huawei Quidway S9300

Table 5-49 Description of buttons and indicators on the G48VA panel
Indicator/Button Color Meaning
RUN/ALM Green If the indicator is on, it indicates that the board
is powered on but the software is not running.
If the indicator blinks once every 2s (0.5 Hz),
it indicates that the system is in normal state.
If the indicator blinks once every 0.25s (4 Hz),
it indicates that the system is being started.
Red
If the indicator is in red, it indicates that the
board is faulty.
Orange If the indicator is in orange, it indicates that
the board is installed in the slot and is powered
on.
Link/ACT Green If the indicator is on, it indicates that the link
is connected.
If the indicator blinks, it indicates that data is
being transmitted.
5.10.4 Interfaces
Table 5-50 describes the types and functions of the interfaces on the G48VA.
Table 5-50 Types and functions of the interfaces on the G48VA
Name
Quantity Description
10M/100M/1000M
BASE-T electrical
interface
48 The G48VA provides 48 Ethernet electrical interfaces
(10M/100M/1000M auto sensing) to transmit and
receive Ethernet services.
The G48VA provides the PoE function and can
provide DC power for the directly connected devices
such as the IP phone, WLAN AP, and Web camera.
5.10.5 Interface Attributes
Table 5-51 describes the attributes of the 100M/1000M Base-T Ethernet interface.
Table 5-51 Attributes of the 100M/1000M Base-T Ethernet interface
Attribute
Description
Connector type RJ45
