Huawei Quidway S9300

Buttons and Indicators on the Panel
Table 5-14 describes the buttons and indicators on the MCUA panel.
Table 5-14 Description of the buttons and indicators on the MCUA panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the
MCUA is powered on, but the software is not
running.
If the indicator blinks every 2s (0.5 Hz), it
indicates that the system is running normally.
If the indicator blinks every 0.25s (4 Hz), it
indicates that the system is starting.
Red
If the indicator is in red, it indicates that the
MCUA is faulty.
Orange If the indicator is in orange, it indicates that
the MCUA is installed, and the board is
powered on.
ACT Green This indicator shows whether the MCUA is
the master MCUA or the slave MCUA.
If the indicator is on, it indicates that the
MCUA is the master MCUA.
If the indicator is off, it indicates that the
MCUA is the slave MCUA.
RST
- Press this button to reset the board.
5.3.4 Interfaces
Table 5-15 describes the types and functions of the interfaces on the MCUA.
Table 5-15 Types and functions of the interfaces on the MCUA
Name
Quantity Description
ETH (10M/100M
Base-TX auto-
sensing)
1 Used to connected to the network interface of
the configuration terminal or the network
management workstation. The configuration
environment thus can be established on site or
remotely.
Console interface 1 Used to connect to the console to implement
on-site system configuration of the S9300.
