Huawei Quidway S9300

To Next Page

To Previous Page

Attribute Description

Operation mode Transmission rate:

l Clock frequency synchronization: 2 MHz, 2 Mbit/s, 1.544 Mbit/s.

l Time synchronization: 9600 bit/s

Supports full-duplex mode.

Compliance

standard

Clock frequency synchronization: E1 and T1

Time synchronization: DCLS and Time of Day (TOD)

5.23.5 Technical Specifications

Table 5-133 describes the technical specifications of the CKM.

Table 5-133 Technical specifications of the CKM

Item Specification

Board dimensions

(depth x width x

height)

145.0 mm × 100.0 mm ×2.0 mm

Power

consumption

6 W

Weight 0.1 kg

Quidway S9300 Terabit Routing Switch

Hardware Description 5 Boards

Issue 01 (2010-12-15) Huawei Proprietary and Confidential

5-101
