8.1 Boards Supported by the S9300
This section describes the boards supported by the S9300.
NOTE
Currently, the LPUs of the S9300 can be classified into S-series boards, E-series boards, F series boards
and EPON board. The details are as follows:
l The S-series boards include only the SA boards, for example, 24-port 100M/1000M Ethernet optical
interface card (SA, SFP)-32K MAC
l The E-series boards include EA, EC, and ED boards, for example, 48-port 100M/1000M Ethernet
optical interface card (EA, SFP)-32K MAC
l The F-series boards include only FA boards, for example, 48-port 1000M Ethernet optical interface
card (FA, SFP)-32K MAC
l The EPON board provides 12 1000M EPON optical interfaces and 12 100M/1000M optical interfaces
(SFP).
Table 8-1 lists the boards supported by the S9300.
Table 8-1 Boards supported by the S9300
Board
Type
Name Description
SRU SRUA Main control board applied to the S9312 and S9306.
The unidirectional switching capacity is 256 Gbit/s
SRUB Main control board applied to the S9312 and S9306.
The unidirectional switching capacity is 512 Gbit/s
MCU MCUA Main control board applied to the S9303. The
unidirectional switching capacity is 256 Gbit/s
CKM CKMA Clock Pinch Board-1588
CMU CMUA Centralized Monitoring Unit, used to monitor the
operation of the S9312 and S9306, providing two
interfaces: RS485 and MON
SPU VAMPA Value-added service (VAS) board
FSU FSUA Flexible service subcard on the SRU, enhancing service
processing capability on the SRU
VSU VSTSA Stack interface flexible pluggable Card on the SRU,
used to provide the switch stacking function
LPU X48SSA 48-Port 10GBASE-X Interface Card(SA,SFP+)
G24CA 24-Port 100/1000BASE-X and 8-Port 100/1000BASE-
T Interface Card(SA,SFP/RJ45)
G24SA 24-Port 100/1000BASE-X Interface Card
(SA,SFP)-32K MAC
X12SA 12-Port 10GBASE-X Interface Card(SA,SFP+)
8 List of Boards
Quidway S9300 Terabit Routing Switch
Hardware Description
8-2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-12-15)
