Huawei Quidway S9300

Table 5-67 Description of buttons and indicators on the F48T panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the LPU
is powered on, but the software is not running.
If the indicator blinks every 2s (0.5 Hz), it
indicates that the system is in normal state.
If the indicator blinks every 0.25s (4 Hz), it
indicates that the system is starting.
Red
If the indicator is in red, it indicates that the
board is faulty.
Orange If the indicator is in orange, it indicates that
the board is inserted in the subrack and is
installed, and the board is powered on.
Link/ACT Green If the indicator is on, it indicates that the link
is connected.
If the indicator blinks, the data is being
transmitted or received.
5.13.4 Interfaces
Table 5-68 describes the types and functions of the interfaces on the F48T.
Table 5-68 Types and functions of the interfaces on the F48T
Name
Quantity Description
10M/100M BASE-T
electrical interface
48 The F48T provides 48 Ethernet electrical
interfaces (10Mbit/s or 100 Mbit/s) to
transmit and receive Ethernet services.
5.13.5 Interface Attributes
Table 5-69 describes the attributes of the 100M Base-T Ethernet interface.
Table 5-69 Attributes of the 10M/100M Base-T Ethernet interface
Attribute
Description
Connector type RJ45
Compliance
standard
IEEE 802.3
