Huawei Quidway S9300

Connector
X1
Connector X2 Color Relation
X1.7 X2.7 White/Brown
Table 6-9 Pin assignments of the crossover cable
Connector
X1
Connector X2 Color Relation
X1.6 X2.2 Orange Pair
X1.3 X2.1 White/Orange
X1.2 X2.6 Green Pair
X1.1 X2.3 White/Green
X1.4 X2.4 Blue Pair
X1.5 X2.5 White/Blue
X1.8 X2.8 Brown Pair
X1.7 X2.7 White/Brown
6.5.3 Technical Specifications
Table 6-10 describes the technical specifications of the straight-through cable. Table 6-11
describes the technical specifications of the crossover cable.
Table 6-10 Technical specifications of the straight-through cable
Item
Specification
Connector
X1/X2
Network interface connector-Crystal connector-8PIN-8 bits-Shield-Plug-24
to 26 AWG-CAT 6/SFTP network cable
Power cable Communication cable-100±15 non-shield enhanced 5 types-CAT5E SFTP 24
AWG-8-core PANTONE 445 U
Number of
cores
8 cores
Fire-
resistance
CM
Length 5 m, 10 m, 20 m, or 30m
6 Cables
Quidway S9300 Terabit Routing Switch
Hardware Description
6-10 Huawei Proprietary and Confidential
