Huawei Quidway S9300

To Next Page

To Previous Page

Table 5-42 Attributes of 1000M colorized optical modules

Attrib

ute

Description

Transm

ission

distanc

80 km

Center

wavele

ngth

1471

1491

1511

1531

1551

1571

1591

1611

Transm

itting

power

0 dBm to 5.0 dBm

Receiv

sensitiv

ity

-28.0 dBm

Overlo

optical

power

-9.0 dBm

Extinct

ion

ratio

8.5 dB

5.8.6 Technical Specifications

Table 5-43 describes the technical specifications of the G48S.

Table 5-43 Technical specifications of the G48S

Item

Specification

Board dimensions

(depth x width x

height)

426.8 mm x 394.7 mm x 35.1 mm

Maximum power

consumption

G48SA: 75 W

G48SC: 92 W

G48SD: 110 W

G48SFA: 65 W

5 Boards

Quidway S9300 Terabit Routing Switch

Hardware Description

5-40 Huawei Proprietary and Confidential

Issue 01 (2010-12-15)
