Cable Description Length
Single cable-straight-through cable-1 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I)
1 m
Single cable-straight-through cable-1.50 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I)
1.5 m
Single cable-straight-through cable-2.00 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I), DL3470
2 m
Single cable-straight-through cable-3.00 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I)
3 m
Single cable-straight-through cable-5.00 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I), DL4538
5 m
Single cable-straight-through cable-10.00 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I), DL2761
10 m
Single cable-straight-through cable-30.00 m-(8-bit network interface-I)-
(CC4P0.5 gray)-(8-bit network interface-I), DL4217
30 m
Single cable-straight-through cable connecting Hub and computer-40.00
m-(8-bit network interface-I)-(CC4P0.5 gray)-(8-bit network interface-I)-
PDH-HONET,DL4218
40 m
Single cable-straight-through cable connecting Hub and computer-60 m-
(8-bit network interface-I)-(CC4P0.5 gray)-(8-bit network interface-I)-
HONET,DL3702
60 m
SMB/SMB Trunk Cable
The type of the SMB/SMB trunk cable is: Trunk cable-2.00 m-75 ohm-2.2 mm-(SMB75SF-V)-
(SYFVZ75-1.2/0.25)-(SMB75SF-V)-HONET,DL4362. The two ends of the cable is SMB
connectors. The cable length is 2 m.
SMB/BNC Trunk Cable
The type of the SMB/BNC trunk cable is: Trunk cable-10.00 m-75 ohm-2.2 mm-(SMB75SF-
V)-(SYFVZ75-1.2/0.25)-(BNC75SF-V)-STP. One end of the cable is the SMB connector, and
the other end is the BNC connector. The cable length is 10 m.
6.8 Stack Cables
This section describes the structure and technical specifications of the stack cables.
6.8.1 Introduction
6.8.2 Structure
6.8.3 Technical Specifications
