5.1 Introduction
This section provides an overview of the boards supported by the S9300, including board
classification, slot distribution, relation between boards, board appearances, and interfaces on
each board.
5.1.1 Board Classification
5.1.2 Slot Distribution and Board Dimensions
5.1.3 Relation Between Boards
5.1.4 Interfaces on the Boards
5.1.1 Board Classification
NOTE
Currently, the LPUs of the S9300 can be classified into S-series boards, E-series boards, F series boards
and EPON board. The details are as follows:
l The S-series boards include only the SA boards, for example, 24-port 100M/1000M Ethernet optical
interface card (SA, SFP)-32K MAC
l The E-series boards include EA, EC, and ED boards, for example, 48-port 100M/1000M Ethernet
optical interface card (EA, SFP)-32K MAC
l The F-series boards include only FA boards, for example, 48-port 1000M Ethernet optical interface
card (FA, SFP)-32K MAC
l The EPON board provides 12 1000M EPON optical interfaces and 12 100M/1000M optical interfaces
(SFP).
The boards on the S9300 are classified into main control boards, Line Processing Units (LPUs)
and so on. The S9312 and S9306 use the Switch Routing Unit (SRU) as the main control board,
and the S9303 uses the Main Control Unit (MCU) as the main control board. Table 5-1 lists the
names, types, and description of the boards on the S9300.
Table 5-1 Boards supported by the S9300
Board
Type
Name Description
SRU SRUA Main control board applied to the S9312 and S9306.
The unidirectional switching capacity is 256 Gbit/s
SRUB Main control board applied to the S9312 and S9306.
The unidirectional switching capacity is 512 Gbit/s
MCU MCUA Main control board applied to the S9303.
CKM CKMA Clock Pinch Board-1588
CMU CMUA Centralized Monitoring Unit, used to monitor the
operation of the S9312 and S9306, providing two
interfaces: RS485 and MON
SPU VAMPA Value-added service (VAS) board
5 Boards
