Table 5-9 Types and functions of the interfaces on the SRU
Name Quantity Description
ETH (10M/100M
Base-TX auto-
sensing)
1 Used to connected to the network interface of
the configuration terminal or the network
management workstation. The configuration
environment thus can be established on site or
remotely.
Console interface 1 Used to connect to the console to implement
on-site system configuration of the S9300.
BITS interface 2 The CLK1 and CLK2 interfaces on the SRU
map the BITS0 and BITS1 interfaces of the
clock board.
The BITS interfaces are connected to the
BITS device or connected to the BITS
interfaces of other products to synchronize the
time and clock.
5.2.5 Interface Attributes
The following tables describe the attributes of the interfaces on the SRU.
l Table 5-10 describes the attributes of the 10M/100M Base-TX Ethernet interface.
Table 5-10 Attributes of the 10M/100M Base-TX Ethernet interface
Attribute
Description
Connector type RJ45
Compliance
standard
IEEE 802.3
l Table 5-11 describes the attributes of the console interface.
Table 5-11 Attributes of the console interface
Attribute
Description
Connector type RJ45
Operation mode Full duplex Universal Asynchronous Receiver/Transmitter (UART)
Compliance
standard
RS-232
Data equipment
type
Data Circuit-terminating Equipment (DCE)
Quidway S9300 Terabit Routing Switch
Hardware Description 5 Boards
Issue 01 (2010-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-17
