Huawei Quidway S9300

Board
Type
Name Description
F48TFA 48-Port 100BASE-T Interface Card(FA,RJ45)-32K
MAC
S24XA 24-Port 100/1000BASE-X and 2-Port 10GBASE-X
Interface Card(EA,SFP/XFP)-32K MAC
T24XA 24-Port 100/1000BASE-T and 2-Port 10GBASE-X
Interface Card(EA,RJ45/XFP)-32K MAC
G24CEAS 24-Port 100/1000BASE-X and 8-Port 100/1000BASE-
T Combo Interface Card (EA, SFP/RJ45, 1588)-32K
MAC, supporting Ethernet synchronization and 1588
time synchronization.
G24SC 24-Port 100/1000BASE-X Interface Card
(EC,SFP)-128K MAC
G24SD 24-Port 100/1000BASE-X Interface Card
(ED,SFP)-512K MAC
E12GA 12-Port EPON Interface and 12-Port 1000BASE-X
Interface Card (SFP)
X4UXA 4-Port 10GBASE-X Interface Card(EA,XFP)-32K
MAC
X4UXC 4-Port 10GBASE-X Interface Card(EC,XFP)-128K
MAC
X4UXD 4-Port 10GBASE-X Interface Card(EC,XFP)-512K
MAC
X2UXA 2-Port 10GBASE-X Interface Card(EA,XFP)-32K
MAC
X2UXC 2-Port 10GBASE-X Interface Card(EC,XFP)-128K
MAC
NOTE
l The GE electrical interfaces do not support the Ethernet synchronization function.
l The Small Form-Factor Pluggable (SFP) is a hot pluggable optical module.
l The 10 Gigabit Small Form-Factor Pluggable (XFP) is a 10G hot pluggable optical module.
l The 10 Gigabit Small Form-Factor Pluggable (SFP+) is a 10G hot pluggable optical module. Its caliber
is smaller than the caliber of the XFP optical module.
5.1.2 Slot Distribution and Board Dimensions
Slots
Figure 5-1, Figure 5-2, and Figure 5-3 show the slots of the S9300.
5 Boards
