Table 5-33 Interfaces on the VAMPA and their functions
Interface Quantity Description
Console interface 1 Provides a serial interface. A user can log in to the local
SPU by connecting the serial interface on the host and
the console interface on the SPU through a cable to
configure the SPU locally.
Ethernet interface 1 Provides an FE electrical interface. A user can log in to
the SPU through Telnet to configure the SPU.
5.7.5 Attributes of Interfaces on the SPU
This topic describes connector types, attributes, operation modes, and compliance standards of
the interfaces on the panel.
Table 5-34 and Table 5-35 describe attributes of the interfaces on the panel.
Table 5-34 Serial interface attributes
Attribute Description
Connector type RJ45
Interface attribute RS232
Compliance standard EIA/TIA-232
Table 5-35 Ethernet interface attributes
Attribute
Description
Connector type RJ45
Interface attribute 10BASE-T/100BASE-TX
Operation mode Full duplex
Compliance standard IEEE 802.3
5.7.6 Technical Specifications
This topic describes technical specifications of the SPU, such as board dimensions, panel
dimensions, maximum power consumption, and weight.
Table 5-36 describes technical specifications of the VAMPA.
