Huawei Quidway S9300

Board
Type
Name Description
G24SD 24-Port 100/1000BASE-X Interface Card
(ED,SFP)-512K MAC
E12GA 12-Port EPON Interface and 12-Port 1000BASE-X
Interface Card (SFP)
X4UXA 4-Port 10GBASE-X Interface Card(EA,XFP)-32K
MAC
X4UXC 4-Port 10GBASE-X Interface Card(EC,XFP)-128K
MAC
X4UXD 4-Port 10GBASE-X Interface Card(EC,XFP)-512K
MAC
X2UXA 2-Port 10GBASE-X Interface Card(EA,XFP)-32K
MAC
X2UXC 2-Port 10GBASE-X Interface Card(EC,XFP)-128K
MAC
NOTE
l Small Form-Factor Pluggable (SFP) is a hot pluggable optical module. The SFP optical module must
be a GE optical module. If an FE optical module is used, the link on the interface cannot be Up.
l The 10 Gigabit Small Form-Factor Pluggable (XFP) is a 10G hot pluggable optical module.
l The 10 Gigabit Small Form-Factor Pluggable (SFP+) is a 10G hot pluggable optical module. Its caliber
is smaller than the caliber of the XFP optical module.
l By default, the transmission rate of an optical interface is 1000M and the 100M/1000M auto-negotiation
is not supported. To use the 100M optical interface, you must set it manually.
8.2 Power Consumption and Weight
This section describes the power consumption and weight of boards.
Table 8-2 shows the power consumption and weight of the boards on the S9300. Suppose that
the temperature in the equipment room is 25°C.
Table 8-2 Power consumption and weight of boards
Board
Maximum Power
Consumption
Weight
LE02SRUA 81 W (including FSUA) 2.80 kg
LE03SRUA 87 W (including CKMA and
FSUA)
2.80 kg
LE02MCUA 18 W 0.90 kg
8 List of Boards
Quidway S9300 Terabit Routing Switch
Hardware Description
