Huawei Quidway S9300 Hardware Description

Table 5-90 Interface attributes of the optical interface card (10G Base-XFP)
Attribute Description
Connector type LC/PC
Optical interface
attribute
Depending on the SFP optical module. For details about the attributes
of the optical module, see Table 5-91.
Compliance
standard
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network
protocol
IP
Table 5-91 Attributes of the XFP optical module (10 Gbit/s)
Attribute Description
Transmissi
on distance
300 m 10 km 40 km 80 km
Center
wavelength
850 nm 1310 nm 1550 nm 1550 nm
Transmitti
ng power
-7.3 dBm to -1.3
dBm
-6.0 dBm to -1.0
dBm
-1.0 dBm to 2.0
dBm
0 dBm to 4 dBm
Receiver
sensitivity
-7.5 dBm -11.0 dBm -15.0 dBm -24.0 dBm
Overload
optical
power
-1.0 dBm 0.5 dBm -1.0 dBm -7.0 dBm
Extinction
ratio
3.0 dB 6.0 dB 8.2 dB 9.0 dB
Fiber type Multi-mode Single-mode
5.16.6 Technical Specifications
Table 5-92 describes the technical specifications of the S24XA.
Table 5-92 Technical specifications of the S24XA
Parameter
Description
Board dimensions
(depth x width x
height)
426.8 mm x 394.7 mm x 35.1 mm
5 Boards
Quidway S9300 Terabit Routing Switch
Hardware Description
5-74 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-12-15)
