Table 5-123 Attributes of the XFP optical module (10 Gbit/s)
Attribute Description
Transmissio
n distance
300 m 10 km 40 km 80 km
Center
wavelength
850 nm 1310 nm 1550 nm 1550 nm
Transmittin
g power
-7.3 dBm to -1.3
dBm
-6.0 dBm to -1.0
dBm
-1.0 dBm to 2.0
dBm
0 dBm to 4 dBm
Receiver
sensitivity
-7.5 dBm -11.0 dBm -15.0 dBm -24.0 dBm
Overload
optical
power
-1.0 dBm 0.5 dBm -1.0 dBm -7.0 dBm
Extinction
ratio
3.0 dB 6.0 dB 8.2 dB 9.0 dB
Fiber type Multi-mode Single-mode
5.21.6 Technical Specifications
Table 5-124 describes the technical specifications of the X4UX.
Table 5-124 Technical specifications of the X4UX
Item
Specification
Board dimensions
(depth x width x
height)
426.8 mm x 394.7 mm x 35.1 mm
Maximum power
consumption
X4UXA: 64 W
X4UXC: 75 W
X4UXD: 76 W
Weight X4UXA: 2.16 kg
X4UXC: 2.28 kg
X4UXD: 2.30 kg
5.22 X2UX - 2-Port 10GBASE-X Interface Card (XFP)
This section describes the 2-Port 10GBASE-X Interface Card (EA,XFP) and 2-Port 10GBASE-
X Interface Card (EC,XFP), including the appearance, functions and features, panel, interface
attributes, and technical specifications.
