Table 5-65 describes the technical specifications of the F48S.
Table 5-65 Technical specifications of the F48S
Item Specification
Board dimensions
(depth x width x
height)
426.8 mm x 394.7 mm x 35.1 mm
Maximum power
consumption
F48SA: 64 W
F48SC: 76 W
Weight F48SA: 2.54 kg
F48SC: 2.66 kg
5.13 F48T - 48-Port 100/1000BASE-T Interface Card (RJ45)
This section describes the 48-Port 100BASE-T Interface Card (EA,RJ45) , 48-Port 100BASE-
T Interface Card (EC,RJ45) and 48-Port 100BASE-T Interface Card (FA,RJ45) , including the
appearance, functions and features, panel, and technical specifications.
5.13.1 Introduction
5.13.2 Function and Application
5.13.3 Panel
5.13.4 Interfaces
5.13.5 Interface Attributes
5.13.6 Technical Specifications
5.13.1 Introduction
The 48-port FE electrical interface card (RJ45) of the S9300 is called F48T for short. The F48T
boards are classified into the following types: (EA, RJ45), (EC,RJ45) and (FA, RJ45).
Table 5-66 provides the full name of the boards and capacities of the MAC address tables.
Table 5-66 Lists of F48T
Full Name
Short Name Capacity of MAC
Address Table
48-Port 100BASE-T Interface Card (EA,
RJ45)
F48TA 32K
48-Port 100BASE-T Interface Card (EC,
RJ45)
F48TC 128K
5 Boards
Quidway S9300 Terabit Routing Switch
Hardware Description
5-56 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-12-15)
