5.18.2 Function and Application
5.18.3 Panel
5.18.4 Interfaces
5.18.5 Interface Attributes
5.18.6 Technical Specifications
5.18.1 Introduction
The 24-port 100M/1000M optical interface card (SFP) of the S9300 is called G24S for short.
The G24S boards are classified into the following types: (SA, SFP), (EC, SFP), and (ED, SFP).
Table 5-99 provides the full name of the boards and capacities of the MAC address tables.
Table 5-99 Lists of G24S
Full Name Short Name Capacity of MAC
Address Table
24-Port 100/1000BASE-X Interface Card
(SA, SFP)
G24SA 32K
24-Port 100/1000BASE-X Interface Card
(EC, SFP)
G24SC 128K
24-Port 100/1000BASE-X Interface Card
(ED, SFP)
G24SD 512K
NOTE
The G24SC and the G24SD have the same appearance.
5.18.2 Function and Application
Function Description
The G24S provides 24 GE optical interfaces to implement data access and wire-speed switching.
Application
The G24S can be installed in any LPU slot on the S9312, S9306, or S9303.
5.18.3 Panel
Figure 5-29 and Figure 5-30 show the appearances of the G24S panels.
Quidway S9300 Terabit Routing Switch
Hardware Description 5 Boards
Issue 01 (2010-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-79
