Huawei Quidway S9300

Table 5-128 Attributes of the 10G Base-XFP optical interface
Attribute Description
Connector type LC/PC
Optical interface
attribute
Depending on the XFP optical module. For details about the attributes of
the optical module, see Table 5-129.
Compliance
standard
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
Table 5-129 Attributes of the XFP optical module (10 Gbit/s)
Attribute Description
Transmissio
n distance
300 m 10 km 40 km 80 km
Center
wavelength
850 nm 1310 nm 1550 nm 1550 nm
Transmittin
g power
-7.3 dBm to -1.3
dBm
-6.0 dBm to -1.0
dBm
-1.0 dBm to 2.0
dBm
0 dBm to 4 dBm
Receiver
sensitivity
-7.5 dBm -11.0 dBm -15.0 dBm -24.0 dBm
Overload
optical
power
-1.0 dBm 0.5 dBm -1.0 dBm -7.0 dBm
Extinction
ratio
3.0 dB 6.0 dB 8.2 dB 9.0 dB
Fiber type Multi-mode Single-mode
5.22.6 Technical Specifications
Table 5-130 describes the technical specifications of the X2UX.
Table 5-130 Technical specifications of the X2UX
Item
Specification
Board dimensions
(depth x width x
height)
426.8 mm x 394.7 mm x 35.1 mm
