Huawei Quidway S9300

Indicator/Button Color Description
ACT Amber If the indicator blinks, the data is being
transmitted or received.
LINK Green-yellow If the indicator is on, it indicates that the link
is connected.
5.18.4 Interfaces
Table 5-101 describes the types and functions of the interfaces on the G24S.
Table 5-101 Types and functions of the interfaces on the G24S
Name Quantity Description
100/1000BASE-X
optical interface
24 The G24S provides 24 Ethernet optical
interfaces (100M/1000M auto sensing) to
transmit and receive 1000 Mbit/s Ethernet
services.
5.18.5 Interface Attributes
The G24S has only the data interfaces. Each interface has an optical module. Table 5-102, Table
5-103 and Table 5-104 show the attributes of the interfaces and the optical modules on the G24S.
Table 5-102 Attributes of the 1000M Base-SFP Ethernet optical interfaces
Attribute
Description
Connector type LC/PC
Optical interface
attribute
Depending on the optical module..
Compliance
standard
IEEE 802.3z
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
