Huawei Quidway S9300

Buttons and Indicators on the Panel
Table 5-61 describes the buttons and indicators on the F48S panel.
Table 5-61 Description of buttons and indicators on the F48S panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the LPU
is powered on, but the software is not running.
If the indicator blinks every 2s (0.5 Hz), it
indicates that the system is in normal state.
If the indicator blinks every 0.25s (4 Hz), it
indicates that the system is starting.
Red
If the indicator is in red, it indicates that the
board is faulty.
Orange If the indicator is in orange, it indicates that
the board is inserted in the subrack and is
installed, and the board is powered on.
ACT Amber If the indicator blinks, the data is being
transmitted or received.
LINK Green-yellow If the indicator is on, it indicates that the link
is connected.
5.12.4 Interfaces
Table 5-62 describes the types and functions of the interfaces on the F48S.
Table 5-62 Types and functions of the interfaces on the F48S
Name
Quantity Description
100M BASE-FX
optical interface
48 The F48S provides 48 Ethernet optical
interfaces (100 Mbit/s) to transmit and receive
100 Mbit/s Ethernet services.
5.12.5 Interface Attributes
The interface of the F48S has only the data interfaces. Each interface has an optical module.
Table 5-63 and Table 5-64 show the attributes of the interface and the optical module.
