Total
Power
Consum
ption
Description
Cross-
sectional
area of
the
conducto
r
16 mm^2 25 mm^2 35 mm^2
Power
cable
Electronic and
electrical
cable-227IEC02
(RV)-16 mm^2-
(blue, black, red, or
green-yellow)
Electronic and
electrical
cable-227IEC02
(RV)-25 mm^2-
(blue, black, red, or
green-yellow)
Electronic and
electrical
cable-227IEC02
(RV)-35 mm^2-
(blue, black, red, or
green-yellow)
Terminal 16 mm^2 power
cable terminal
25 mm^2 power
cable terminal
35 mm^2 power
cable terminal
Less than
3200 W
Power
distance
- 27.7 m 38.8 m
Cross-
sectional
area of
the
conducto
r
- 25 mm^2 35 mm^2
Power
cable
- Electronic and
electrical
cable-227IEC02
(RV)-25 mm^2-
(blue, black, red, or
green-yellow)
Electronic and
electrical
cable-227IEC02
(RV)-35 mm^2-
(blue, black, red, or
green-yellow)
Terminal - 25 mm^2 power
cable terminal
35 mm^2 power
cable terminal
6.2 AC Power Cable
This section describes the structure and technical specifications of the AC power cables.
6.2.1 Introduction
6.2.2 Structure
6.2.3 Technical Specifications
