Table 5-53 Description of buttons and indicators on the G48CEAT panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the board
is powered on but the software is not running.
If the indicator blinks once every 2s (0.5 Hz),
it indicates that the system is in normal state.
If the indicator blinks once every 0.25s (4 Hz),
it indicates that the system is being powered
on or being restarted.
Red
If the indicator is on, it indicates that the board
is faulty.
Orange If the indicator is on, it indicates that the board
is installed in a slot and the CBUS is powered
on.
ACT indicator of
optical interfaces
Amber If the indicator blinks, it indicates that data is
being transmitted.
Link indicator of
optical interfaces
Green-yellow If the indicator is on, it indicates that the link
is connected.
ACT/Link
indicators of
electrical interfaces
Green
l If the indicator blinks, it indicates that data
is being transmitted.
l If the indicator is on, it indicates that the
link is connected.
5.11.4 Interfaces
Table 5-54 describes the types and functions of the interfaces on the G48CEAT.
Table 5-54 Types and functions of the interfaces on the G48CEAT
Name
Quantity Description
100M/1000M BASE-X
optical interface
12 The G48CEAT provides 12 100M/1000M optical
interfaces to transmit and receive GE services.
10M/100M/1000M
BASE-T electrical
interface
36 The G48CEAT provides 36 10M/100M/1000M
electrical interfaces to transmit and receive GE
services.
5.11.5 Interface Attributes
The G48CEAT provides only data interfaces. An optical interface can be connected to an optical
module. Table 5-55, Table 5-56 and Table 5-57 describe the attributes of the optical interfaces
Quidway S9300 Terabit Routing Switch
Hardware Description 5 Boards
Issue 01 (2010-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-49
