Huawei Quidway S9300

Component Description Reference
Power supply The power supplies are installed in slots PWR1
and PWR2. The S9303 can use DC or AC power
supplies.
See 3 Power
Supply.
Cabling rack The cable distribution posts are located on the
right side of the board cage of the S9303.
-
Cable The cables of the S9303 include internal cables
(such as power cables and signal cables), optical
fibers, and external cables.
See 6 Cables.
2.3 System Configuration and Physical Specifications
This section describes the system configuration and physical specifications of the S9300.
2.3.1 System Configuration
2.3.2 Physical Specifications
2.3.1 System Configuration
Table 2-4 System configuration of the S9300
Item
Configuratio
n of the S9312
Configuratio
n of the S9306
Configuratio
n of the
S9303
Note
Processor 700 MHz
(Dominant
frequency)
700 MHz
(Dominant
frequency)
500 MHz
(Dominant
frequency)
-
DDR2
SDRAM
1 GB 1 GB 512 MB -
NVRAM 512 KB 512 KB 512 KB Battery supply
Flash 64 MB 64 MB 64 MB -
CF card 512 MB 512 MB 512 MB The CF card serves as a
mass storage device to
save data files and logs.
Switching
capacity
1 Tbit/s or 2
Tbit/s
1 Tbit/s or 2
Tbit/s
720 Gbit/s Bidirectional
Backplane
capacity
12 Tbit/s 6 Tbit/s 3 Tbit/s Bidirectional
10GE port
density
576 288 144 -
