RJ45 Direction DB25 DB9 Signal
6 <--- 2 3 TXD (Transmit Data)
7 <--- 20 4 DTR (Data Terminal Ready)
8 <--- 4 7 RTS (Request to Send)
6.4.3 Technical Specifications
Table 6-7 describes the technical specifications of the Console cable.
Table 6-7 Technical specifications of the Console cable
Item Specification
Connector
X1
Cable connector-D style-25PIN-Plug
Connector
X2
Network interface connector-Crystal connector-8PIN-8 bits-Connector
Connector
X3
Cable connector-D style-9PIN-Plug
Fire-
resistance
CM
6.5 Ethernet Cable
This section describes the structure and technical specifications of the Ethernet cables.
6.5.1 Introduction
6.5.2 Structure
6.5.3 Technical Specifications
6.5.1 Introduction
Ethernet cables are classified into the straight-through cable and the crossover cable.
Straight-through Cable
The straight-through cable is used to connect the Ethernet interfaces between the following
devices:
l Router and hub
l Router and LAN switch
