Figure 5-3 Slots of the S9303

LPU

MCU MCU

LPU

4/5

Table 5-2, Table 5-3, and Table 5-4 describe the slot distribution on the S9300.

Table 5-2 Slot distribution of the S9312

Slot Quant

ity

Height Note

1-12 12 35 mm Slots for LPUs

13, 14 2 35 mm Slots for SRUs in 1+1 backup mode

Table 5-3 Slot distribution on the S9306

Slot

Quant

ity

Height Note

1-6 6 35 mm Slots for LPUs

7, 8 2 35 mm Slots for SRUs in 1+1 backup mode

Table 5-4 Slot distribution on the S9303

Slot

Quant

ity

Height Note

1-3 3 35 mm Slots for LPUs

4, 5 2 19.8 mm Slots for MCUs in 1+1 backup mode

Board Dimensions

Table 5-5 provides the dimensions of each board of the S9300. For the definitions of depth,

width, and height of a board, see Figure 5-4.

5 Boards

Quidway S9300 Terabit Routing Switch

Hardware Description

5-8 Huawei Proprietary and Confidential

Issue 01 (2010-12-15)
