Buttons and Indicators on the Panel
Table 5-126 describes the buttons and indicators on the X2UX panel.
Table 5-126 Description of buttons and indicators on the X2UX panel
Indicator/Button Color Description
RUN/ALM Green If the indicator is on, it indicates that the LPU
is powered on, but the software is not running.
If the indicator blinks every 2s (0.5 Hz), it
indicates that the system is running normally.
If the indicator blinks every 0.25s (4 Hz), it
indicates that the system is starting.
Red
If the indicator is in red, it indicates that the
LPU is faulty.
Orange If the indicator is in orange, it indicates that
the LPU is installed, and the board is powered
on.
ACT Amber If the indicator blinks, the data is being
transmitted or received.
LINK Green-yellow If the indicator is on, it indicates that the link
is connected.
5.22.4 Interfaces
Table 5-127 describes the types and functions of the interfaces on the X2UX.
Table 5-127 Types and functions of the interfaces on the X2UX
Name
Quantity Description
10G BASE-X optical
interface
2 The X2UX provides two 10GE BASE-X
optical interfaces to transmit and receive 10
Gbit/s Ethernet services.
5.22.5 Interface Attributes
The X2UX has only the data interfaces. Each interface has an optical module. Table 5-128 and
Table 5-129 show the attributes of the interfaces and the optical modules on the X2UX.
Quidway S9300 Terabit Routing Switch
Hardware Description 5 Boards
Issue 01 (2010-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-97
