Buttons and Indicators on the Panel
Table 5-106 describes the buttons and indicators on the X12SA panel.
Table 5-106 Description of buttons and indicators on the X12SA panel
Indicator/Button Color Meaning
RUN/ALM Green If the indicator is on, it indicates that the board
is powered on but the software is not running.
If the indicator blinks once every 2s (0.5 Hz),
it indicates that the system is in normal state.
If the indicator blinks once every 0.25s (4 Hz),
it indicates that the system is being powered
on or being restarted.
Red
If the indicator is in red, it indicates that the
board is faulty.
Orange If the indicator is in orange, it indicates that
the board is installed in the slot and the CBUS
is powered on.
ACT Amber If the indicator blinks, it indicates that data is
being transmitted.
LINk Green-yellow If the indicator is on, it indicates that the link
is connected.
5.19.4 Interfaces
Table 5-107 describes the types and functions of the interfaces on the X12SA.
Table 5-107 Types and functions of the interfaces on the X12SA
Name
Quantity Description
10G BASE-X optical
interface
12 The X12SA provides 12 10GE optical interfaces
to transmit and receive Ethernet services at 10
Gbit/s.
5.19.5 Interface Attributes
Table 5-108 and Table 5-109 describe the attributes of the 10GE interfaces and the connected
optical modules.
Quidway S9300 Terabit Routing Switch
Hardware Description 5 Boards
Issue 01 (2010-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-85
