Table 9-5 Interface attributes of the GE optical LPU (1000M Base-SFP)
Attribute Description
Connector type LC/PC
Optical interface
attribute
Depending on the SFP optical module. For details about the attributes of
the optical module, see Table 9-6.
Compliance
standard
IEEE 802.3z
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
Table 9-6 Attributes of the SFP optical module (1000 Mbit/s)
Attri
bute
Description
Tran
smiss
ion
dista
nce
500 m 10 km 10 km (single-
mode bidirectional
fiber)
40 km 40 km 80 km 100km
Cent
er
wave
lengt
h
850 nm 1310
nm
Tx:
1310
nm
Rx:
1490
nm
Tx:
1490
nm
Rx:
1310
nm
1310
nm
1550
nm
1550
nm
1550nm
Tran
smitt
ing
powe
r
-9.5
dBm to
-2.5
dBm
-9.0
dBm to
-3.0
dBm
-9.0
dBm to
-3.0
dBm
-9.0
dBm to
-3.0
dBm
-5.0
dBm to
0 dBm
-5.0
dBm to
0 dBm
-2.0
dBm to
5.0
dBm
0dBm
to
5dBm
Rece
iver
sensi
tivity
-17.0
dBm
-20.0
dBm
-19.5
dBm
-19.5
dBm
-23
dBm
-22
dBm
-23.0
dBm
-30.0dB
m
Over
load
optic
al
powe
r
0 dBm -3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-9.0dB
m
