9.1 Electrical Interface Attributes
This section describes the attributes of electrical interfaces.
Table 9-1 lists the attributes of electrical interfaces.
Table 9-1 Attributes of the 10Base-T/100Base-TX/1000Base-T-RJ45 electrical interface
Attribute Description
Connector type RJ45
Compliance
standard
IEEE 802.3
Frame format Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol IP
9.2 10GE Optical Interface Attributes
This section describes the attributes of 10GE optical interfaces.
Each interface of the 10GE optical LPU has an optical module. Table 9-2, Table 9-3 and Table
9-4 show the attributes of the interface and the optical module.
NOTE
l The SFP+ and the XFP are 10G hot-pluggable optical modules. Compared with the XFP, the SFP+ has
smaller width.
l The 10G SFP+ and XFP optical modules support LAN access and WAN access functions.
Table 9-2 Interface attributes of the 10GE optical LPU
Attribute
Description
Connector type LC/PC
Optical interface
attribute
Depending on the SFP+ or XFP optical module. For details about the
attributes of the optical module, see Table 9-3 and Table 9-4.
Compliance
standard
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network protocol IP
