Board Maximum Power

Consumption

Weight

LE03MCUA 26 W (including CKMA) 0.92 kg

SRUB 105 W (including CKMA and

FSUA)

2.90 kg

CMUA 1 W 0.22 kg

VAMPA 120 W 3.1kg

FSUA 20 W 0.42 kg

VSTSA 12 W 1 kg

G48SA 75 W 2.54 kg

G48SC 92 W 2.66 kg

G48SD 110 W 2.66 kg

G48SFA 65 W 2.60 kg

G48TA 62 W 2.50 kg

G48TC 68 W 2.62 kg

G48TD 98 W 2.62 kg

G48TFA 48 W 2.50 kg

G48CEAT 62 W 2.50 kg

G48VA 64 W (excluding PoE power

consumption)

2.6 kg

F48SA 64 W 2.54 kg

F48SC 76 W 2.66 kg

F48TA 59 W 2.50 kg

F48TC 70 W 2.62 kg

F48TFA 40 W 2.30 kg

S24XA 65 W 2.4 kg

G24CEAS 70 W 2.7 kg

G24CA 67 W 2.26 kg

G24SA 45 W 2.22 kg

G24SC 63 W 2.66 kg

G24SD 75 W 2.66 kg

T24XA 53 W 2.3 kg

Quidway S9300 Terabit Routing Switch

Hardware Description 8 List of Boards

Issue 01 (2010-12-15) Huawei Proprietary and Confidential

8-5
