Huawei Quidway S9300

To Next Page

To Previous Page

Item Specification

Maximum power 350 W (full configuration)

Noise at normal temperature 58.6 db

Weight Full configuration 22 kg

DC input Rated voltage -48V/-60 V DC

Allowed voltage -48 V:- 38.4 V to -57.6 V DC

-60 V:- 48 V to -72 V DC

AC input Rated voltage 110/220 V AC, 50/60 Hz

Allowed voltage 100 V to 120 V and 200 V to 240 V AC, 50/60 Hz

Environmental

temperature

Long-term 0°C to 45°C

Short-term -5°C to 55°C

Storage -40°C to 60°C

Humidity Long-term 5% RH to 85% RH, non-condensing

Short-term 0% RH to 95% RH, non-condensing

Storage 0% RH to 95% RH, non-condensing

Altitude Long-term < 3000 m

Storage < 5000 m

2 Overview of the S9300

Quidway S9300 Terabit Routing Switch

Hardware Description

2-14 Huawei Proprietary and Confidential

Issue 01 (2010-12-15)
