Dynamic Performance Measurement
• The most typical dynamic performance measurement consists of
looking for distortion in the frequency domain
• This is done by sending a pure sinusoidal input and looking at the
output
Conceptual Dynamic Test Setup
ADC
Under Test
Perfect
DAC
f
dB
f
dB
Distortion
or noise
