Real Measurement of
Dynamic Performance
• There is no such thing as a perfect DAC…
• To improve the precision and simplify the post-processing,
all the spectrum analysis is done in digital form and in
software.
ADC
Under Test
f
dB
Computer
Acquisition Board (Like
National Instruments)
