Other Dynamic Measurements
• All the timing and control signals (i.e. Convert,
Data_Ready, Read, Data, …) must be tested at full speed
to ensure their functionality,
input analog voltage
digital output code
transition point
Sparkling
• The output from a sinewave
input can also be observed in
time-domain to make sure
there is no sparkling (sudden
out-of-range samples).
