XA User Guide 6-94 4/17/98
DIVU.d Rd, #data16
(unsigned 32 bits / 16 bits --> 16 bit quotient, 16 bit remainder)
Bytes: 4
Clocks: 22
Operation: (Rd) <-- 16-bit integer portion of (Rd) / #data16 (unsigned divide)
(Rd+1)<-- 16-bit remainder of (Rd) / #data16
Encoding:
byte 3: upper 8 bits of #data16
byte 4: lower 8 bits of #data16
1 1 1 0 1 0 0 1 d d d 0 0 0 0 1
