3/24/97 9-13 8051 Compatibility
ADDS [R+], #data4 Add a short value to an indirect offset address,
with the indirect pointer automatically
incremented.
ADDS [R+offset8/16], #data4 Add a short value to an indirect offset address
(with 8 or 16-bit offset).
ADDS direct, #data4 Add a short value to a direct address.
MOVS ..., #data4 Move short data to destination using any of the
same addressing modes as ADDS.
ASL R, R Arithmetic shift left a byte, word, or double word,
up to 31 places, shift count read from register.
ASR R, R Arithmetic shift right a byte, word, or double word,
up to 31 places, shift count read from register.
LSR R, R Logical shift right a byte, word, or double word,
up to 31 places, shift count read from register.
ASL R, #DATA4/5 Arithmetic shift left a byte, word, or double word,
up to 31 places, shift count read from instruction.
ASR R, #DATA4/5 Arithmetic shift right a byte, word, or double word,
up to 31 places, shift count read from instruction.
LSR R, #DATA4/5 Logical shift right a byte, word, or double word,
up to 31 places, shift count read from instruction.
DIV R, R Signed divide of 32 bits register by 16 bit register,
or 16 bit register by 8 bit register.
DIVU R, R Unsigned divide of 32 bit register by 16 bit
register, or 16 bit register by 8 bit register.
MUL R, R Signed multiply of 16 bit register by 16 bit
register, or 8 bit register by 8 bit register.
MULU R, R Unsigned multiply of 16 bit register by 16 bit
register.
DIV R, #data8/16 Signed divide of 32 bits register by 16 bit
immediate, or 16 bit register by 8 bit immediate.
DIVU R, #data8/16 Unsigned divide of 32 bit register by 16 bit
immediate, or 16 bit register by 8 bit immediate.
MUL R, #data8/16 Signed multiply of 16 bit register by 16 bit
immediate, or 8 bit register by 8 bit immediate.
Table 9.3: Instructions and addressing modes new to the XA
New Instructions and Addressing Modes
