Table 48: AMP1 (BT8A78AMP1) Specifications (continued)
SpecificationItem
Optical Performance
1528.77 nm to 1566.72 nmWavelength
0 dB to 23 dBSupported Span Loss
0 dB to 10 dBSupported DCM Loss
19 dB to 21dBMonitor Port Loss
-4.0 dBm to 21.0 dBmLine Launch Power
+/-0.8 dBPower Monitor Accuracy
1510 nmOSC Wavelength
10.709 GbpsSupported Bit Rates
27.952 Gbps
111.809 Gbps
120.579 Gbps
Class 1 Hazard 1MOptical Safety
APSD (Line port)Optical Safety Protection Mechanisms
APR (DCM and C1 ports)
Span Loss ControlOptical Control Features
Tilt Control
DCM Loss Compensation
See “Service Module LEDs” on page 151.LEDs
The port is operating normally.Active (Green)Port LEDs
A fault exists on the port.Fault (Amber)
Copyright © 2019, Juniper Networks, Inc.132
BTI7800 Series Hardware Overview and Installation Guide
